This is the 7th post of the TypeScript Compiler Series and these are the posts we've talked about before:

• A High Level Architecture of the TypeScript compiler
• JavaScript scope, Closures, and the TypeScript compiler
• A Deep Dive into the TypeScript Compiler Miniature
• Implementing StringLiterals for the TypeScript Compiler
• Building EmptyStatement and Semicolon as a statement ender for the TypeScript compiler
• Allow var statements to declare multiple symbols in the TypeScript compiler

In this post, we'll be talking about Let declarations.

As always, we'll see some examples, go through the lexer to check new tokens, create new AST nodes in the parser, handle redeclaration of Let in the binder, handle some errors in the type checker, and transform and emit JS code. We'll also add a simple support for es2015, which will handle the transformation of let declarations into var declarations.

Before, the mini TS compiler only allowed us to use var to declare variables. Now we'll implement let which's very similar but has some differences in behavior.

To start off, let's see two examples.

The first one declares variables using the let keyword.

let x = 1;
let y = 2;

And the second generates an error because let doesn't allow the usage of the variable before its declaration. So if you do something like:

variable;
let variable = 1;

We'll need to see an error: Variable 'variable' is used before being assigned.

Lexer: adding missing tokens for Let declarations

The missing token in the lexer phase is the keyword let. So, whenever we are going through the source code and building tokens, we need to be able to check the string let and create a token Let.

Then, the first step is to create the token type.

export enum Token {
  Function = 'Function',
  Var = 'Var',
+ Let = 'Let',
  Type = 'Type',
  Return = 'Return',
  Equals = 'Equals',
  NumericLiteral = 'NumericLiteral',
  Identifier = 'Identifier',
  Newline = 'Newline',
  Semicolon = 'Semicolon',
  Colon = 'Colon',
  Comma = 'Comma',
  Whitespace = 'Whitespace',
  String = 'String',
  Unknown = 'Unknown',
  BOF = 'BOF',
  EOF = 'EOF',
}

Now we can read the source code to generate this new token.

The logic handle it is already done, because we're already handling some keywords like var, type, etc. Here's the code:

if (/[_a-zA-Z]/.test(s.charAt(pos))) {
  scanForward(isAlphanumerical);
  text = s.slice(start, pos);
  token =
    text in keywords
      ? keywords[text as keyof typeof keywords]
      : Token.Identifier;
}

When reading the source code, we need to check if the text is or not a keyword. If it is, we get it from the keywords object to build the token. Otherwise, it's just an identifier token.

So the only missing implementation here is to add the let in the keywords object.

const keywords = {
  function: Token.Function,
  var: Token.Var,
+ let: Token.Let,
  type: Token.Type,
  return: Token.Return,
};

Now we are ready to start parsing the tokens and creating the AST node for let.

Parser: handling let declarations

As we've seen in the previous post, the AST for variable declaration is something like this:

VariableStatement
  declarationList: VariableDeclarationList
    declarations: VariableDeclaration[]

We have the VariableStatement node with the VariableDeclarationList which will store all variable declarations. If you see, let declarations are no different from var declarations. It can have multiple symbols too. The node is pretty much the same.

But how do we differentiate if it's variable coming from a let declaration or var declaration?

We'll start using the concept of flags. The node has this new flags attribute that's just a number. For now, it can be two different flags:

• None: when it's a var declaration
• Let: when it's a let declaration

The flags can hold multiple “meanings” and this is how it's defined for now.

export const enum NodeFlags {
  None = 0,
  Let = 1 << 0,
}

And this flags attribute will be stored in the VariableDeclarationList level. It means that, for any variable declaration in the list, they are related to a let or var declaration.

Let's do a quick recap on how we handle var, so we can make sense on what's missing for let.

Whenever we have a var token, we parse it:

if (tryParseToken(Token.Var)) {
  return parseVariableStatement();
}

Parsing the variable statement is pretty much creating the whole structure for VariableStatement that will have the VariableDeclarationList and the list of VariableDeclaration.

Here it's:

function parseVariableStatement(): VariableStatement {
  const pos = lexer.pos();
  return {
    kind: Node.VariableStatement,
    pos,
    declarationList: {
      kind: Node.VariableDeclarationList,
      declarations: parseVariableDeclarations(),
      pos,
    },
  };
}

function parseVariableDeclarations() {
  const declarations: VariableDeclaration[] = [];
  do {
    const name = parseIdentifier();
    const typename = tryParseToken(Token.Colon) ? parseIdentifier() : undefined;
    parseExpected(Token.Equals);
    const init = parseExpression();
    declarations.push({
      kind: Node.VariableDeclaration,
      name,
      typename,
      init,
      pos: lexer.pos(),
    });
  } while (tryParseToken(Token.Comma));
  return declarations;
}

If the flags attribute will be in the VariableDeclarationList level, we should just add a value based on which type of declaration was used with the help of NodeFlag.

When parsing the variable statement, we should receive the flags and it will be stored in the node:

function parseVariableStatement(flags: NodeFlags): VariableStatement {
  const pos = lexer.pos();
  return {
    kind: Node.VariableStatement,
    pos,
    declarationList: {
      kind: Node.VariableDeclarationList,
      declarations: parseVariableDeclarations(),
      flags,
      pos,
    },
  };
}

So when the parser handles the Var token, it should pass the NodeFlags.None to this function

if (tryParseToken(Token.Var)) {
  return parseVariableStatement(NodeFlags.None);
}

If the let declaration is pretty much the same and the only difference is the flag, when parsing the Let token, we should just call the same parseVariableStatement function, which will create the entire AST node, but now with the NodeFlags.Let.

if (tryParseToken(Token.Let)) {
  return parseVariableStatement(NodeFlags.Let);
}

And now we parse both tokens with pretty much the same AST node. The only way to differentiate them is by using the flags attribute.

Binder: handling variable redeclarations

Let's see these examples below.

When re-declaring the same identifier with var:

var num = 0;
var num = 1;

When re-declaring the same identifier with let:

let num = 0;
let num = 1;

When re-declaring the same identifier with let when it was declared with var

var num = 0;
let num = 1;

When re-declaring the same identifier with var when it was declared with let

let num = 0;
var num = 1;

Besides the first one, in all these cases, we want to handle the re-declaration of the same identifier. The first example won't generate any error. The last three will.

And the error message is this:

Cannot redeclare block-scoped variable 'num'; first declared at 0

Before going into the implementation, let's do a quick recap on flags for both AST nodes and symbols.

In the AST node scope, we differentiate var and let with the flags. If it's NodeFlags.None, it's var, if it's a NodeFlags.Let, it's let.

In the scope of the symbol, we can have None, FunctionScopedVariable (for var), BlockScopedVariable (for let or const), and Type (for type alias).

That's how we know if the node is a var or let, and when the symbol is a var or let.

These are the possible paths that will generate an error:

• Redeclaring a let
• Redeclaring a var with let
• Redeclaring a let with var

The code will look like this:

const hasOther =
  willRedeclareLet(flags, symbol.flags) ||
  willRedeclareVarWithLet(flags, symbol.flags) ||
  willRedeclareLetWithVar(flags, symbol.flags);

if (hasOther) {
  error(
    declaration.pos,
    `Cannot redeclare ${declaration.name.text}; first declared at ${declaration.pos}`,
  );
}

If one of the paths happens, we need to generate the error. Now we just need to implement those functions.

For let redeclaration, the symbol's flag should be a BlockScopedVariable and the current node's flag should be Let.

function willRedeclareLet(nodeFlags: NodeFlags, symbolFlags: SymbolFlags) {
  return (
    nodeFlags & NodeFlags.Let && symbolFlags & SymbolFlags.BlockScopedVariable
  );
}

The other functions are pretty similar. They should have an expected node flag and the symbols should have an expected symbol flag.

Redeclaring var with let, the node's flag should be Let and the symbol's flag should be a FunctionScopedVariable.

function willRedeclareVarWithLet(
  nodeFlags: NodeFlags,
  symbolFlags: SymbolFlags,
) {
  return (
    nodeFlags & NodeFlags.Let &&
    symbolFlags & SymbolFlags.FunctionScopedVariable
  );
}

And redeclaring let with var, the node shouldn't have a flag (None — a Var node), and the symbol’s flag should be a BlockScopedVariable.

That way, we generate the expected error.

Type checker: handling variable being used before its declaration error

An example of a code that could generate this error is this one:

variable;
let variable = 1;

Using the let declaration, it doesn't allow us to use the variable before its declaration and the type checker should generate an error for this type of code.

The error message for the code above is this one:

Block-scoped variable 'variable' used before its declaration.

Performing this check is pretty simple. Every time we're type checking an identifier, we should check it and see if this node is being accessed before its declaration. The way we do it is based on the position of the declaration and the expression/identifier being accessed.

If the value declaration's position is greater than the identifier's position, we generate the error message.

function checkExpression(expression: Expression): Type {
  switch (expression.kind) {
    case Node.Identifier:
      // ...

      if (isBlockScopedVarUsedBeforeItsDeclaration(symbol, expression)) {
        error(
          expression.pos,
          `Block-scoped variable '${expression.text}' used before its declaration.`,
        );
      }

      // ...
}

When checking an expression, more specifically an identifier, we check if the identifier is being accessed before its declaration. If so, generate the error.

How’s the isBlockScopedVarUsedBeforeItsDeclaration function implementation?

That one is also pretty simple:

function isBlockScopedVarUsedBeforeItsDeclaration(
  symbol: Symbol,
  expression: Expression,
) {
  const isBlockScopedVar = symbol.flags & SymbolFlags.BlockScopedVariable;
  return isBlockScopedVar && symbol.valueDeclaration!.pos > expression.pos;
}

First, we need to ensure that the variable is a let declaration. The way we do it is based on the symbol’s flag. Do you recall that BlockScopedVariable means let (and in the future const)? This should be the first check. Then we compare the positions between the let declaration and the identifier being accessed.

If it passes, we generate the error.

Transformer: Supporting old versions of JS

That's a very interesting idea that improved the mini TS compiler. The new implementation allows compiling the code to old versions of JS. So, for this particular case, if we need to support ES2015 or es5, the output can have let declarations. They should be transformed into var declarations.

In the end, it should just rename the node’s name text from let to var.

The first important concept I want to share is the transformation based on the compiler options. Yeah, the tsconfig.json file you always see on TypeScript projects.

The transform function will receive these options and based on it, it can have a better transformation for the source code.

export function transform(
  statements: Statement[],
  compilerOptions: CompilerOptions,
) {
  switch (compilerOptions.target) {
    case 'es5':
      return es2015(typescript(statements));
    default:
      return typescript(statements);
  }
}

When the target is es5, it will run an es2015 function to transform the code for us before doing the default transformation.

When transforming each statement, we need to check if the variable statement is a BlockScopedVariable based on the statement flag and if so, call the transformLetIntoVar function to transform let to var.

function transformStatement(statement: Statement): Statement[] {
  switch (statement.kind) {
    case Node.VariableStatement:
      return statement.declarationList.flags & SymbolFlags.BlockScopedVariable
        ? transformLetIntoVar(statement)
        : [statement];
    default:
      return [statement];
  }
}

For the transformLetIntoVar function, we just need to change the declaration's name text from let to var and that's it.

function transformLetIntoVar(statement: VariableStatement) {
  return [
    {
      ...statement,
      declarationList: {
        ...statement.declarationList,
        declarations: statement.declarationList.declarations.map(
          (declaration) => ({
            ...declaration,
            name: { ...declaration.name, text: 'var' },
          }),
        ),
      },
    },
  ];
}

The entire variable statement should keep the same. We just need to update the text.

That way, we can output es2015 based on the compiler options configuration, very similar to what we have on the tsconfig.json.

Final words

In this piece of content, my goal was to show the whole implementation of let declarations:

• How to build tokens and structure the AST to support list of let declarations
• How to type check let and handle errors
• How to transform let into var

I hope it can be a nice source of knowledge to understand more about the TypeScript compiler and compilers in general. This is part of my last 5 months I've been studying, researching, and working on the TS compiler miniature.
